Is swapping out a carbine buffer setup on a midlength dpms 308 for a a5 buffer setup worth it. What spring/ buffer combo should be used.
-
Having trouble using the site?
Contact support
A-5 Buffer setup 308 help
- Thread starter Yeti-george
- Start date
The actual A5 length buffer will not work in an AR10. If your buffer is the standard AR15 carbine length you are already using the A5 length receiver extension, it is where they originated. If you have the extra short buffer, you are using a standard length carbine receiver extension.
With the different lengths and profiles of large frame bolt carriers there is not a lot of easy mix and match here, stick with the profiles the OEM shipped it with.
This is a major pain point for franken-gun AR10 builds as there are so many conflicting standards.
Then JP SCS which does fit LFAR platforms. Pair with a JP LoMass BCG and tune the gas along with the adjustable buffer weights and springs to get the lowest reciprocating weight that will still run the gun reliably. It's not a complicated process and results in the lowest recoil/ shortest recoil cycle I've felt on a 308W gas gun.
You will not be using an A5 buffer with a large frame DPMS in an A5/ArmaLite RET, but the A5 RET is what you want.
The ArmaLite/A5 RET is great for the large frame carbines because you can use a longer AR-10 spring and the common AR-15 carbine length buffers, vs the tiny little DPMS LR-308 carbine buffers that kinda suck.
The biggest problem with using a standard AR-15 carbine RET with a large frame AR is that they don’t allow enough spring length to fit in there. The A5 RET allows a full-length extra power AR-10 rifle spring, so when you pair that with an AR-15 carbine buffer, the guns run like they’re supposed to.
ArmaLite Inc. was probably the first company to crack the code of reliability with an AR-10 carbine in the 2000s. KAC had a lot of problems with the early SR-25K and MLGS 16” SR-25s using standard AR-15 carbine RETs. They went to mid-length RETs and longer action springs quite some time ago.
It's not filled with oil. I don't think you know what it is. And there's nothing more proprietary than a VLTOT A5 buffer tube and buffers.
It'll help a little bit especially if you add an adjustable gas block and a muzzle brake
What model rifle do you have exactly and do you handload?
The spring length/weight is more important than the buffer weight.
Buffer weight is really to counter carrier bounce in full auto guns.
Port diameter and spring weight really are the main places to tame the system into an optimum cyclic rate window.
Buffer weight is really to counter carrier bounce in full auto guns.
Port diameter and spring weight really are the main places to tame the system into an optimum cyclic rate window.
I've found the Tubbs flat wire spring combined with a Kynshot hydraulic buffer provides a very soft recoil impulse. This is in an A5 length receiver extension tube. I don't recall which model buffer I used. I've used the hydraulic buffer for 2500+ rounds without any issues.
Yeah, don't do this if you want reliability. You will have headache after headache. Just get the Armalite AR10 RET kit with the tube, spring, buffer, and castle nut from everygunpart.com and then use the heaviest buffer that you can that gives you 3 o'clock ejection.
Have you shot that set-up both in the extreme cold and summer?
One of the challenges with hydraulic fluid cylinders and temperature gradients is loss of the seals from cycles in varying temp and pressure environments. They work amazingly-well with such a smooth feel to the action, until they fail.
2500rds is a good run though. I hope it continues to work for you for another 2500rds.
They have always interested me.
I have two LFARs that use this setup with no problems. Both are 100% reliable. Mixing and matching parts in the LFAR is where you run into trouble on these platforms, which is what you're suggesting
I've not used it in extreme cold. I'd say it's been run between 40 and 90F. It's in a gas gun I use for prs.
kynshot must have got their shit together then. back when they started those where junk. had 2 of them in 5.56 cal destroy themselves inside of 500 rounds.
why did endine stop selling their hydraulic buffers? i know they came from .mil and those work great, i still have one that keeps going.
endine makes smaller versions for manufacturing equipment for things that reciprocate. i have them on some small printing machines. they last for ever.
i have an original endine hydraulic buffer and have not seen any issues regarding temps hot or cold but i live in s. az. its been shot plenty in the heat.
Th heat is great for seals as long as you stay within a pretty narrow temperature range (flatland AZ).
Once you start cycling through a wide temp range, things shrink all around, including seals. Add the normal cylinder pressure and the fluid often finds a way to get out.
There are som cool Aerospace solutions to that though, but they’re expensive (cryogenic cooling pre-fitment).
