Atlas BT10 vs Atlas PSR bipod?

Sendit6.5

Private
Full Member
Minuteman
Apr 29, 2009
467
47
Sabinal, TX
www.brushyhill.com
What is the difference between these 2 bipods, other than about $40? I'm looking at buying one and I can't decide whether there's any reason to spend the extra $$. I haven't done a lot of prone shooting in a long time. So I don't have any hands-on experience with Atlas bipods to draw on.

What's the difference and which one would YOU choose.....and why??


Sent from my iPhone using Tapatalk

The PSR is essentially the same as the BT10 v8.1 with non-rotating legs, stronger inner legs and fore/aft limiting bosses. If you are USING the bipod rough-and-tumble, the PSR is probably the one you want. For bench/range and most PRS-style matches, a BT10 is fine.

The PSR is essentially the same as the BT10 v8.1 with non-rotating legs, stronger inner legs and fore/aft limiting bosses. If you are USING the bipod rough-and-tumble, the PSR is probably the one you want. For bench/range and most PRS-style matches, a BT10 is fine.

this ^^ except for i would 100% recommend the PSR for prs matches...i have ran atlas since i first started competing...the BT10s were good for about 1 yr before they were sloppy/loose and had to go back for refurb...my PSR has been going strong for 2 yrs now and is still tight and solid...DEFINITELY worth the extra cost

  • Wow
Reactions: deersniper
I have the same question. I have seen the answer written a few times and it is in their FAQ. I'm still having a hard time visualizing "These changes include non-rotational legs, fore and aft pivot limiting bosses (which are two pegs that help keep the muzzle level when loading a rifle to the bipod)". Any help here would be appreciated. I think I might just need to go and put these side by side and see for myself. I use a BT10 V8 today.

I think I might just need to go and put these side by side and see for myself.

OK, how about this. Here are the BT10 and BT46(PSR) "side-by-side".

BT10 on top, BT46 on the bottom showing the pivot limiting boss (duplicated on the other side also):


Again, BT10 on top, BT46 on bottom showing the slot in the inner leg and extended boss with setscrew on outer leg that prevents outer leg rotation:


Closer picture of the BT46 slotted inner leg:



  • Like
Reactions: SilentXIII
Non-rotational legs are stiffer and won't roll on you when loading the bipod. The pivot-limiting bosses significantly limits the amount of forward (and rearward) flex or forward pivot when loading the bipod.

Never found the rotating legs to be a hindrance. I don't have to load the ever living shit out of the bipod to shoot.

This was off a concrete firing line with a plain ol BT10:
Howa 1500 10 shot grp 2018.jpg


So how again is leg flex and rotation hindering me?

Never found the rotating legs to be a hindrance. I don't have to load the ever living shit out of the bipod to shoot.

This was off a concrete firing line with a plain ol BT10:
View attachment 6998403

So how again is leg flex and rotation hindering me?

If my memory serves me correct, I believe it was a requirement set by USSOCOM. That would be a question best asked to those involved when they spec'd out the desired features.

If my memory serves me correct, I believe it was a requirement set by USSOCOM. That would be a question best asked to those involved when they spec'd out the desired features.
Thanks. I think I'll rely on my own experience with the BT10, which I find lacking in no way at all.
