I've not posted anything on this scope since I'm not as knowledgeable or experienced as most others on the Hide. I was hoping that ILya would have his review posted by now. But since there are a few members asking questions, I decided to put my foot in it... I've had the scope for just over 1 week.
I have the Leica PRS 5-30x56i with the Ballistic Reticle. Purchased the scope from
@gr8fuldoug at Camera Land NY. Great to work with, free shipping and no sales tax for Texas... Bought the Spuhr mount from
@Mile High Shooting, also very helpful, great to work with and free shipping. They checked to make sure that there were no know issues when using the Spuhr 4602 and the Leica PRS prior to taking the order.
The scope is mounted on a LMT MWS AR, 24" barrel, 6.5 Creedmoor, Spuhr 6 Mil mount. It's not the PRB reticle that most are interested in.
Leica PRS Ballistic reticle.
View attachment 7313851
If you have questions that are not addressed below, please let me know.
I'm no expert and have only used this scope and a Steiner T5Xi 5-25 SCR. So I don't have a lot to compare it to. The Steiner with the SCR reticle is very similar to the Ballistic reticle on the Leica.
One of the things I noticed was the width of the subtensions on center cross hair of the Leica is 0.04 Mils. Whereas the subtensions on center cross hair of the Steiner is 0.03 Mils. I prefer the thinner subtensions on the Steiner. It's not much thiner but can be noticed at maximum magnification.
Although subjective and with little to compare it to, the clarity of the glass on the Leica is very good. Colors are realistic and image is bright. I did not notice any CA. I've only been on the range in the midday sun, few clouds. The clarity and CA on the Leica PRS is better than that on my Steiner T5Xi.
We really need to hear what ILya has to say about this...
The turrets are solid and the detents are crisp/tactile, no mush or play. The magnification adjustment is smooth with good tension. Same goes for the parallax and illumination rings. All markings are clear and legible.
Setting zero on the elevation turret is toolless and easy. Simply flip up what Leica calls the locking toggle, turn counter clockwise to unscrew and pull out the locking toggle from the turret. The elevation turret can then be pulled off. Reposition the elevation turret, to 0, and press down to engage the turret. Then replace the locking toggle and turn clockwise to tighten. The zero on the windage turret is set using the same method.
Below is an image of the locking toggles flipped up.
View attachment 7313835
Elevation locking toggle removed.
View attachment 7313836
Elevation turret removed.
View attachment 7313837
Setting the zero stop is very easy and quick but does require the use of the supplied allen wrench. You can see the zero stop in the image above. It's on the upper brass piece.
Below is an image of from the Leica manual on setting the zero stop.
View attachment 7313838
The allen wrench is hidden under the windage locking toggle. Below is an image of the windage turret with the locking toggle removed to expose the allen wrench.
View attachment 7313839
Below are 2 pictures of the elevation locking toggle, removed.
View attachment 7313841
View attachment 7313842
Parallax was easy to set. The parallax ring only has numbers at 20 yards and 100, marks of varying width and length at other locations on the ring. When zeroing the scope at 100, the parallax ring matched up well. Adjusting the parallax at distances between 200 - 700 yards was not difficult.
View attachment 7313843
Illumination is good, but only just barely noticeable in bright midday Texas sun. The illumination ring can be turned fully in either direction, no stops, but detents for each on/off setting. There is an off setting between each of the brightness settings.
The diopter was very quick and easy to set. My eyes are old and I need reading glasses, so I had to dial a little positive on the diopter. The diopter does not have a locking ring.
View attachment 7313844
The Leica PRS 5-30x56i has a total of 32 Mils of elevation. After zeroing the scope for my rifle, LMT MWS 24" barrel 6.5 Creedmoor, with a 6 Mil Spuhr mount, I had 19.5 Mils of elevation to work with.
The elevation rotation indicator is an interesting design. As you rotate the elevation knob, the rotation indicator moves up and down, revealing the number of rotations. Below are 3 images.
Rotation indicator at zero elevation, for my rifle. Note that it is not flush with the top of the turret and the number 1 is exposed. This is due to the zero for my rifle being 12.5 Mils above the lowest possible elevation setting.
View attachment 7313845
Rotation indicator at beginning of the 2nd rotation, 10 Mils of elevation.
View attachment 7313846
Rotation indicator at 19.5 Mils of elevation. Maximum elevation for my rifle.
View attachment 7313847
Here's some technical data from Leica. It also come with lens caps, not listed below...
Battery is a Lithium 2032 coin cell.
View attachment 7313848
View attachment 7313849
I've been at the range 2 different times with this scope. Once to zero the scope at 100 yards and shoot at 200 yards. Another time to shoot from 200 - 700 yards.
I have not performed a tall target test/tracking test.
The scope was very easy to bore site at 25 yards and zero at 100 yards. The corrections that I needed to make were measured with the reticle and the amount of correction dialed on the turrets matched.
Here's one of the pictures I took while zeroing the rifle at 100 yards. Ammo used was Hornady American Gunner 140gr BTHP. LMT MWS 24" barrel, 6.5 Creedmoor, 6 Mil Spuhr mount.
View attachment 7313850
At 200 yards, I dialed the amount of elevation indicated in the Hornady 4DOF ballistic app and made first round impact on a 3" steel target. I switched to a 2" steel target with frist round impact and then to a 1" steel target, all at 200 yards. I was able to hit the 1" target 1/2 of the time. I lost my 2" steel target after the rubber conveyer strap that it was hanging from broke.
When shooting from 200 - 700 yards, 8 MOA targets at 100 yard intervals, I was able make 1st round impacts on the targets when dialing the elevation indicated in the 4DOF app. Return to zero worked correctly. I did not have to dial any windage since the wind was at 12:00. That said, 8 MOA targets are pretty big...
I hope that this answer some of the questions that members may have about the Leica PRS 5-30x56i Ballistic Reticle.
