Does anyone have a blueprint showing the location of the side mount iron sight holes for the Rem 700?

[SingleshotFredd]

Once upon a time Remington sold their 700s with two holes drilled and tapped into the side of the action to allow customers to mount peep sights.

I'm hoping to find a print showing the locations and dimensions of these holes so that I can have them installed on other Rem 700 footprint actions.

I know it's a total shot in the dark here but nothing ventured nothing gained and all that.



[JLPTG]



[SingleshotFredd]

View attachment 8447489

And how does that help me? I see no dimensions saying it's x amount of thousandths from this position or that positiin.



[Wonko_The_Sane]

And how does that help me? I see no dimensions saying it's x amount of thousandths from this position or that positiin.

The blue print seems to show their exact dimension? In line with the rear sight rail holes, at 90 degree index.



[SingleshotFredd]

The blue print seems to show their exact dimension? In line with the rear sight rail holes, at 90 degree index.

I'm not a machinist or engineer so I wasn't quite sure.



[Wonko_The_Sane]

I'm not a machinist or engineer so I wasn't quite sure.

I mean, one would assume there is a bit of the knowledge if asking for the dimension. From what I can tell in the image, 3.629-3.631" center line from the rear scope screw, and .604-.606" center line spacing between the two, 90 degree over. Looks to match up with rear sight pad threaded holes.



[SingleshotFredd]

I mean, one would assume there is a bit of the knowledge if asking for the dimension. From what I can tell in the image, 3.629-3.631" center line from the rear scope screw, and .604-.606" center line spacing between the two, 90 degree over. Looks to match up with rear sight pad threaded holes.

Well for a $1500 action I'd like it to be right but I suppose I'll just have to roll the dice and hope for the best.



[RPN]

If you can't make sense of that drawing then pay someone who can.
Everything you need is on there.

Sometimes you just need to do what you do so you can pay someone to do what they do.



[lash]

Well for a $1500 action I'd like it to be right but I suppose I'll just have to roll the dice and hope for the best.

Who’s doing the actual work, you or a gunsmith? If you were planning on doing it and cannot read a print, you’re in way over your head. Take the print and the actions to a competent gunsmith or even any competent machinist.

If you do it yourself, you truly better hope for the best.



[SingleshotFredd]

Who’s doing the actual work, you or a gunsmith? If you were planning on doing it and cannot read a print, you’re in way over your head. Take the print and the actions to a competent gunsmith or even any competent machinist.

If you do it yourself, you truly better hope for the best.

With any luck it'll be done by the action maker before it leaves the building.



[Mike Casselton]

And how does that help me? I see no dimensions saying it's x amount of thousandths from this position or that positiin.

I looked at the drawing for about twelve seconds.
The side holes are along the centerline.
Front to back they are even with the rear scope mount holes on the top.

Seems pretty simple.

ETA: fixed the auto-incorrect



[roostercogburn98]

I looked at the drawing for about twelve seconds.
The side holes are along the centerline.
Front to back they are even with the rear scope mount hooked on the top.

Seems pretty simple.

Asks for blueprints with dimensions, gets them and doesn’t know how to read blueprints lol.






What




The





Fuck



[lash]

On the plus side, because I’m that annoying guy who sees the good…

SH came through with his answer, since there’s a great spread of knowledge here. For the record, I’m impressed with @JLPTG for being so quick to post that print.



[Terry Cross]

I'm not a machinist or engineer so I wasn't quite sure.

So you were asking for something that you have no concept of?
Someone could have posted a picture of a blue #4 Uno card and you would have been just as happy?

With any luck it'll be done by the action maker before it leaves the building.

Any shop that is in the business of manufacturing a usable rifle action would be quite pleased to have a dimensional drawing as detailed as the print that @JLPTG freely and accurately supplied to you if they didn't already have access to it.
